ECH-NP-4

ECH-NP-4

IP Paging Console

Main Features:

• Professional Design: Professional paging microphone design with high-grade aluminum alloy shell for durability and reliability.
• High-Definition Display: Equipped with a 4-inch digital true color capacitive touch screen with 480×480 resolution.
• Mobile App Control: Supports "Easy Mic" mobile app for paging zone configuration and scheduled bell ringing tasks.
• Live Paging Support: Supports live paging announcements to all zones, designated zones, or designated IP endpoints.
• Built-in Audio Components: Includes a built-in 3W loudspeaker and unidirectional condenser microphone for live paging, two-way hands-free intercom, and audio monitoring.
• Digital Audio Processor: Built-in digital audio processor improves audio quality and enhances noise reduction performance.
• Audio Mixing: Built-in ultra-compact mixing console supports 5-channel audio source mixing including MIC, AUX1, AUX2, Bluetooth, and USB flash drive.
• Web Management: Built-in web server supports management of up to 30 IP endpoint devices.
• Firmware Management: Supports easy configuration and online firmware upgrades through a user-friendly web interface.
• SIP Compatibility: Compatible with standard SIP protocol and supports VoIP systems including Cisco, Asterisk, and Yealink.
• Relay Input Support: Equipped with relay input terminal for connection with external detection devices for triggering emergency notification tasks.
• Network Connectivity: Standard RJ45 Ethernet port supporting cross-segment and cross-router communication.
